Santi Adapter Cable: Santi Plug to Heizteufel Plug
Adapter cable: SantiTM socket/coupling to HeizteufelTM cinch socket/coupling
60W power booster for Santi connectors
The adapter variants at a glance:
Santi (f) to 1 x Heizteufel (f)
Santi (f) to 2 x Heizteufel (f)
Santi (f) to 4 x Heizteufel (f)
Santi (f) to 1x Santi (m) + 1x/2x Heizteufel (f)
Santi (f) with 1 x booster to 1 x Heizteufel (f)
Santi (f) with 2 x booster to 2 x Heizteufel (f)
Polarity of the Santi socket/coupling/female:
The suitable adapter for the connection of heating clothing with the power supply cable of the dry suit grommet consists of a Santi plug (socket/coupling/female) and 1 or 2 Heizteufel RCA sockets (female), optionally with different lengths of 20cm or 150cm, plus if necessary. a Santi plug (pins, male, with sleeve). The respective connectors are waterproof according to IP68 and assembled with flexible cables. This adapter allows a valuable extension of attractively priced accessories to heating clothing from the HeizteufelTM production.
60W power booster for Santi connectors
If the original heating power of external, nominal 11.1V LiPo battery tanks via Santi plugs should not be sufficient for a desired target temperature, Heizteufel helps with its 60W power booster a factor x 1.8 higher heating heat for its heatable gloves, socks and underwear. Please note the following instructions here: Your heated clothing must have a heating control due to the enormous heat increase of ~80%, but at least. a shut-off device that protects against overheating problems . And a maximum of only 2 power boosters may be used for one Santi plug (max. current carrying capacity = 10A @ 12V). The dimensions of a power booster are 65mm x 25mm x 15mm, 10cm cable per input and output, input voltage 9~13VDC.
The adapter variants at a glance:
Santi (f) to 1 x Heizteufel (f)
Santi (f) to 2 x Heizteufel (f)
Santi (f) to 4 x Heizteufel (f)
Santi (f) to 1x Santi (m) + 1x/2x Heizteufel (f)
Santi (f) with 1 x booster to 1 x Heizteufel (f)
Santi (f) with 2 x booster to 2 x Heizteufel (f)
Note: Before using the adapter, make sure that the polarity of the power source and power consumers to be connected is correct. To do this, measure the voltage of the Santi battery tank and compare the polarity with the polarity shown here. Basically, the cinch assignment of Heizteufel plug connections is +V on the inside and -V on the outside. A warranty on third-party products due to faulty connections is excluded.
Polarity of the Santi socket/coupling/female:
In the photo is shown a Heizteufel adapter, RCA coupling to a Santi coupling for Santi Push-Lock plug.
- IMPORTANT NOTE: Items with custom design are excluded from the right of return or exchange. (see page right of withdrawal / reasons for exclusion and expiry) -.
Adapter connections:
Power input: Santi female/coupling/female with molded strain relief.
Power output: RCA socket/coupling/female, waterproof with molded strain relief
Current carrying capacity: max. 10A
Adapter cable length: 20cm (other cable length is possible after consultation)
Compatibility: is guaranteed with all HeizteufelTM heating products
Power input: Santi female/coupling/female with molded strain relief.
Power output: RCA socket/coupling/female, waterproof with molded strain relief
Current carrying capacity: max. 10A
Adapter cable length: 20cm (other cable length is possible after consultation)
Compatibility: is guaranteed with all HeizteufelTM heating products
Adapter cable
